EE 420L Analog Integrated Circuit Design Lab

Authored by: Frank Sanchez

Spring 2017

Lab1Lab safety review and then review of basic RC circuits, due January 25

Lab2Operation of a compensated scope probe, due February 10

Lab3Op-amps I, basic topologies, finite gain, and offset, due February 15

Lab4 : Op-amps II, gain-bandwidth product and slewing, due February 22

Lab5 : Op-amps III, the op-amp integrator, due March 8

Lab6Single-stage transistor amplifiers, due March 22

Lab7Design of an audio amplifier, due March 29

Lab8Characterization of the CD4007 CMOS transistor array, due April 5

Lab9Design of a Beta-Multiplier Reference (BMR) using the CD4007 CMOS transistor array, due April 19

Project : Design a transimpedance amplifier (TIA)-with a gain of 30k
